High Resolution Indoor Fixed LED DisplayP4 Led Video Wall Easy To Install

Basic Information
Place of Origin: Guangdong, China
Brand Name: Longrun
Model Number: P4 Black-1/16scan
Minimum Order Quantity: 5 Square Meter/Square
Price: Negotiable
Packaging Details: P4 Full Color LED video wall, flightcase is recommended.
Supply Ability: 100 Square Meter/Square Meters per Week P4 Full Color LED video wall
Pitch 4mm LED Video Wall Usage: Indoor Pixel Pitch: 4 Mm
LED Type: 2121 Black SMD Pixel Configuration: RGB
Pixels Per Sqm: 62500 Dots Module Size: 128*128 Mm
Brightness: >= 1400cd/sqm Scan Method: 1/16
Fresh Rate: >= 1200Hz Grey Level: 16bit
Usage: Indoor Display Function: Video
Screen Dimension: Pitch 4mm LED Video Wall Size As Your Request Tube Chip Color: FULL COLOR
Pixels: 4mm Port: Shenzhen
High Light:

indoor led panel

,

front service led screen

High Resolution Led Display P4 Led Video Wall Easy To Install Wide Viewing Angle


Product Description
P4 Full Color LED video wall Features:

1. The first level LED chip from Taiwan Epistar.

2. With pure golden wire connection in LED.

3. Grand A row material for module frame and mask.

4. 4 layers PCB and copper plating thickness > 18mil.

5. Ag alloy solder paster to ensure good soldering on PCB.

6. Stainless steel screws when assembly.

7. Die-casting aluminium material cabinet ensures perfect flatness and no gap between cabinets.

8. Disassembly and assembly are quick and easy.

9. Three years warranty.



P4 Full Color LED video wall Technology  Parameters:

Pixel Pitch : 4mm Pixel Density : 62500 dots/ m2
Brightness : ≥1400 cd/m2 Viewing Angle : H:160°, V:120°
LED Specification : SMD 2121 black Pixel Configuration : 1R1G1B
Module Size : 128×128mm Module Pixel Density : 32×32 dots
Driving Method : 1/16 Scan Refresh Rate : ≥960Hz
Gray/Color : 8192Gray, Color 1billion Control System : Synchronous/off-line control system, fiber transmission
Working Voltage : AC 110/220V Working Temperature : -20°C~50°C
Max. Power Consumption : <1000W/m2 Life-span : 75,000~100,000hrs
MTBF : >10,000hrs Dead Dot Rate : <0.0001

Packaging & Shipping

Flightcase ,celluar carton and plywood case for choice.

  1. Flightcase is the most convenient for outdoor led display screen's transportation and diamantling.High Resolution Indoor Fixed LED DisplayP4 Led Video Wall Easy To Install 0
  2. For fixed installation,Celluar carton or plywood case packaging is recommended for save cost.
