| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | LongRun |
| Model Number: | LR-F4-64*32-16SD2121 |
| Minimum Order Quantity: | 1 Piece |
| Price: | Negotiable |
| Application: | Indoor Advertising | Color: | Full Color RGB |
|---|---|---|---|
| Panel Size: | 256*128mm | Pixel Pitch: | 4mm |
| Pitch: | 4mm | LED Type: | 2121SMD |
| Pixels Per Sqm: | 62,500 Dots | Module Size: | 256*128 Mm |
| Module Resolution: | 64*32 | Cabinet Size: | 768*768mm |
| Brightness: | 800-1000cd/sqm | Scan Method: | 1/16 |
| Grey Level: | 16bit | Life Span: | >100,000 Hours |
| Selling Units: | Single Item | Single Package Size : | X45X113 Cm |
| Single Gross Weight: | 160.0 Kg | Package Type: | According To Your Inquiry, Standard Cabinet Fixed Installation,honeycomb Carton Is Recommended To Save Cost; Waterproof Cabinet For Rental,flight Case Is Recommended,as It Is More Convenient For Transportation And Dismantling. |
| High Light: | indoor led panel,front service led screen |
||
Full Color RGB 4mm Led Display , Indoor Led Panel 256*128 Mm Module Size
1. The first level LED chip from Taiwan Epistar.
2. With pure golden wire connection in LED.
3. Grand A row material for module frame and mask.
4. 4 layers PCB and copper plating thickness > 18mil.
5. Ag alloy solder paster to ensure good soldering on PCB.
6. Stainless steel screws when assembly.
7. Disassembly and assembly are quick and easy.
8. Three years warranty.
Parameters:
| P4 SMD Outdoor | |||
| LEDs | Pixel pitch | 4mm | |
| Pixel configuration | 1RGB | ||
| LED type | 211SMD | ||
| LED manufacturer and origin | KNLIGHT | ||
| Cabinet | Pixel pitch | 4mm | |
| Pixels per sqm. | 62,500 pixels | ||
| LEDs qty. per sqm. | 62,500pcs | ||
| LED module resolution | 64x32 | ||
| LED module size | 256*128mm | ||
| LED cabinet resolution | 192(W) x 192(H) cm | ||
| LED cabinet dimension | Width: 768 mm; Height: 768 mm; Depth:100mm | ||
| LED cabinet Area | 0.5898 sqm. | ||
| Brightness | 80-1000cd/sqm | ||
| Viewing angle | Horizontal: 160°; Vertical: 120° | ||
| Grey scale (linear) | 65,396 levels per color | ||
| Display refresh rate | 1920 Hz | ||
| Scan mode | 1/16 scan | ||
| Power supply | Power consumption (max.) | <1200 watts/sqm. | |
| Power consumption (average) | <1000 watts/sqm. | ||
| Input voltage | AC 110 or 220 V ±10% | ||
| Mechanical design | LED cabinet weight | 43kgs | |
| Material | Iron cabinet | ||
| Ingress protection | Waterproof | ||
| Serviceability | Back service | ||
| Operation | Storage environment | Temperature: 0°C-40°C; Humidity: 10%-85%RH | |
| Operating environment | Temperature: -20°C-65°C; Humidity: 10%-90%RH | ||
| Lifespan (typical) | ≥100,000 hours | ||
| MTBF | ≥10,000 hours | ||
| Source compatibility | CVBS,YC, YUV,RGB, DVI, SDI, HD-SDI, HDMI | ||
Stage Background Led Digital Display Screen Module Details:
 |
|
LongRun Optoelectronics Co.,Ltd,a professional indoor and outdoor full color led screen display manufacture,which can offer any kinds of led panel in competitive price.Tag: Led Outdoor TV Billboard ,Stage Background Led Display Big Screen ,Advertising led display,Led video wall,led billboard,led display panel,truck mobile led display,indoor advertising led display screen,stage led screen for concert,outdoor led advertising screen,P4 indoor led exhibition display,theatre led display,led screens for events,rental mobile led screen ect with great quanlity and excellent support after sale.
Our engineers have vast experience in the industry having developed all kinds for led panel solutions includign message boards,graphic panels,time/temperature displays,full color video screen.
Over the years we have installed thousands of led displays into numerous industries-shops,shopping center,corporate offices,factories,call center,government buildings,transport links,stadiums and arenas.
